Артикул: RHT-626-0201 Категория: Datasheet

Authorized Sellers


Request for Quotation

SMB Разъем Прямой Джек Мужской Контакт Панель Монтаж Сквозное Отверстие 75 Ом — RHT-626-0201

Разъем SMB (Sub-Miniature version B) — это быстрозажимной миниатюрный соединитель, работающий на частоте до 4 ГГц. Интерфейс SMB оснащен защелкивающимся механизмом соединения и доступен в 50-омных конфигурациях.
Разъемы SMB меньше, чем разъемы SMA. Однако эти разъемы не идеальны для работы в жестких условиях окружающей среды, поскольку они не такие прочные, как разъемы SMA.

Доступные в конфигурациях 50 Ом и 75 Ом, разъемы SMB выполнены в соответствии со стандартами интерфейса MIL-C-39012, IEC 60169-10 и CECC 22130.

Интерфейс

Сценарии применения



Product Specification

RF Series

SMB Type
Connector Type

Jack
Orientation

Straight
Contact Type

Male Pin
Contact Termination Style

Solder
Mounting Type

Panel Mount
Mounting Feature

Through Hole
Fastening Type

Snap On
Number of Ports

1
Продукция не найдена

75 ohm
Frequency - Max

4GHz
Shell Material

Copper Alloy
Shell Finish

Gold Plated
Insulator Material

Teflon White
Contact Material

Brass
Contact Finish

Gold Plated
Dielectric Withstanding Voltage

1000 VRMS Max
Insultation Resistance

≥1000MΩ
Center Contact Resistance

6 MΩ Max
Outer Contact Resistance

1 MΩ Max
Mating Durability

≥ 500 Cycles
Temperature Range

-65℃ to +165℃
RF Series

SMB Type

 Connector Type

Jack
Orientation

Straight

 Contact Type

Male Pin
Contact Termination Style

Solder

 Mounting Type

Panel Mount
Mounting Feature

Through Hole

 Fastening Type

Snap On
Number of Ports

1

 Продукция не найдена

75 ohm
Frequency - Max

4GHz

 Shell Material

Copper Alloy
Shell Finish

Gold Plated

 Insulator Material

Teflon White
Contact Material

Brass

 Contact Finish

Gold Plated
Dielectric Withstanding Voltage

1000 VRMS Max

 Insultation Resistance

≥1000MΩ
Center Contact Resistance

6 MΩ Max

 Outer Contact Resistance

1 MΩ Max
Mating Durability

≥ 500 Cycles

 Temperature Range

-65℃ to +165℃
RF Series

SMB Type
Connector Type

Jack
Orientation

Straight
Contact Type

Male Pin
Contact Termination Style

Solder
Mounting Type

Panel Mount
Mounting Feature

Through Hole
Fastening Type

Snap On
Number of Ports

1
Продукция не найдена

75 ohm
Frequency - Max

4GHz
Shell Material

Copper Alloy
Shell Finish

Gold Plated
Insulator Material

Teflon White
Contact Material

Brass
Contact Finish

Gold Plated
Dielectric Withstanding Voltage

1000 VRMS Max
Insultation Resistance

≥1000MΩ
Center Contact Resistance

6 MΩ Max
Outer Contact Resistance

1 MΩ Max
Mating Durability

≥ 500 Cycles
Temperature Range

-65℃ to +165℃

"SMB" is a type of small push-on locking RF coaxial connector, characterized by its small size, light weight, convenient use, and excellent electrical performance. It is suitable for connecting coaxial cables in high-frequency circuits of radio equipment and electronic instruments.

Kindly pls see the blew sheet:

Difference Dimension Impedance Frequency Connection type Advantage
SMA Small 50 Ohm 0-18G(26.5G) Screw High frequency,
Small size,
Stable connection
SMB Smaller 50 Ohm
75 Ohm		 0-4G Push-on Small volume,
Easy to plug
Good at anti-vibration

For Cable Type:

Clamp

Solder

For Panel Type:

Through Hole

Edge Mount

Clamp

Bulkhead

Flange

Of course, Renhotec has been specialized in supplying RF connector and cable series for over 15 years, just talk with Renhotec freely, the more details you share, the best support you will get.

Drawing for SMB Connector Straight Jack Male Pin Panel Mount Through Hole 75 OhmDownload
