Renhotec Automotive Series Assemblies

Renhotec Automotive Series Assemblies are specialized components designed specifically for the automotive industry, serving crucial roles in establishing dependable electrical connections between various vehicle systems and components. Engineered to endure the rigorous conditions of automotive environments, these assemblies are constructed from durable materials that withstand vibrations, extreme temperatures, and exposure to automotive fluids, ensuring long-term reliability and performance.

Available in a variety of configurations and types, Renhotec’s automotive series assemblies are tailored to meet diverse automotive applications such as power distribution, signal transmission, and data communication. They comply with stringent industry standards, guaranteeing compatibility and reliability across different vehicle models and manufacturers. These assemblies are integral in connecting vital automotive components including sensors, actuators, lights, and communication systems, thereby enhancing the functionality, efficiency, and safety of modern vehicles.

1st Connector: 2302510-9, Z Code
1st Contact Type: Female Pin
2nd Connector: 2302461-2, B Code
2nd Contact Type: Male Pin
Contact Material: Copper
Impedance: 100 ohm
1st Connector: 2302510-9, Z Code
1st Contact Type: Female Pin
2nd Connector: 2302510-9, Z Code
2nd Contact Type: Female Pin
Contact Material: Copper
Impedance: 100 ohm
1st Connector: 2302510-9, Z Code
1st Contact Type: Female Pin
2nd Connector: 2302461-3, C Code
2nd Contact Type: Male Pin
Contact Material: Copper
Impedance: 100 ohm
1st Connector: 2302510-9, Z Code
1st Contact Type: Female Pin
2nd Connector: 2302461-3, C Code
2nd Contact Type: Male Pin
Contact Material: Copper
Impedance: 100 ohm
1st Connector: 9-1802105-9, A Code
1st Contact Type: Female Pin
Contact Material: Copper
Impedance: 100 ohm
1st Contact Type: Male Pin
2nd Contact Type: Female Pin
Cable Color: Black
Cable Type: RG174
Impedance: 50 ohm
RF Cable 1st Connector: BNC Plug
RF Cable 2nd Connector: Fakra Jack
RF Cable Style: BNC to Fakra C
1st Contact Type: Male Pin
2nd Contact Type: Female Pin
Cable Color: Black
Cable Type: RG174
Impedance: 50 ohm
RF Cable 1st Connector: CRC9 Plug
RF Cable 2nd Connector: Fakra C Jack
RF Cable Style: CRC9 to Fakra C
Durability (Matings): ≧500
Impedance: 50 ohm
Insulation Resistance: ≥1000MΩ
Operating Voltage: 335V max
VSWR: ≤1.5
IP Rating: IP67
Number of Ports: 12
Operating Temperature: -67°F (-55°C) to +257°F (+125°C)
Series: DT Series
Shape: Rectangular
Shell Material: Thermoplastic
IP Rating: IP67
Number of Ports: 2
Operating Temperature: -67°F (-55°C) to +257°F (+125°C)
Series: DT Series
Shape: Rectangular
Shell Material: Thermoplastic
IP Rating: IP67
Number of Ports: 3
Operating Temperature: -67°F (-55°C) to +257°F (+125°C)
Series: DT Series
Shape: Rectangular
Shell Material: Thermoplastic
IP Rating: IP67
Number of Ports: 4
Operating Temperature: -67°F (-55°C) to +257°F (+125°C)
Series: DT Series
Shape: Rectangular
Shell Material: Thermoplastic
