HSD Connector
HSD series consists of high-performance connectors for digital low-voltage differential signals. The HSD series connectors are available for LVDS cameras, USB, and IEEE 1394 applications.
HSD connector portfolio is focused on a variety of automotive applications. Examples include internal compartments for connecting displays, mainframes, cluster displays, and rear seat infotainment modules. In addition, the connector portfolio covers harsh environmental conditions for camera applications, such as bumper areas or rearview mirrors.
The connector portfolio can be used in combination with a variety of protocols. Examples include LVDS (Low Voltage Differential Signaling), GVIF (Gigabit Video Interface), USB, IEEE 1394, and Ethernet protocols.

Quick View

HSD Connector 6P Male

Connector Type: Plug
Contact Type: Male Pin
Shield Termination: Crimp
Quick View

HSD Connector Jack Straight 4 Pin Cable Mount

Cable Color: Beige, Black, Blue, Claret Violet, Cream White, Curry, Gray, Heather Violet, Leaf Green, Light Green, Nut Brown, Pastel Orange, Water Blue, Yellow Green
Connector Type: Jack
Contact Material: Copper
Contact Type: Female Pin
Contacts: 4 Pin
Impedance: 100 ohm
Quick View

HSD Connector Jack Straight 4+2 Pin Cable Mount

Cable Color: Beige, Black, Blue, Claret Violet, Cream White, Curry, Gray, Heather Violet, Leaf Green, Light Green, Nut Brown, Pastel Orange, Water Blue, Yellow Green
Connector Type: Jack
Contact Material: Copper
Contact Type: Female Pin
Contacts: 4+2 Pin
Impedance: 100 ohm
Quick View

HSD Connector Plug R/A 4+8 Pin Panel Mount D Code – 102-11-10002

Cable Color: Claret Violet
Connector Type: Plug
Contact Material: Copper
Contact Type: Male Pin
Contacts: 4+8 Pin
Impedance: 100 ohm
Quick View

HSD Connector Plug Right Angle 4 Pin Panel Mount

Cable Color: Beige, Black, Blue, Claret Violet, Cream White, Curry, Gray, Heather Violet, Leaf Green, Light Green, Nut Brown, Pastel Orange, Water Blue, Yellow Green
Connector Type: Plug
Contact Material: Copper
Contact Type: Male Pin
Contacts: 4 Pin
Impedance: 100 ohm
Quick View

HSD Connector Plug Right Angle 4+2 Pin Panel Mount

Cable Color: Beige, Black, Blue, Claret Violet, Cream White, Curry, Gray, Heather Violet, Leaf Green, Light Green, Nut Brown, Pastel Orange, Water Blue, Yellow Green
Connector Type: Plug
Contact Material: Copper
Contact Type: Male Pin
Contacts: 4+2 Pin
Impedance: 100 ohm
Quick View

HSD Connector Plug Straight 4 Pin Cable Mount

Cable Color: Beige, Black, Blue, Claret Violet, Cream White, Curry, Gray, Heather Violet, Leaf Green, Light Green, Nut Brown, Pastel Orange, Water Blue, Yellow Green
Connector Type: Plug
Contact Material: Copper
Contact Type: Male Pin
Contacts: 4 Pin
Impedance: 100 ohm
Quick View

HSD Connector Plug Straight 4+2 Pin Cable Mount

Cable Color: Beige, Black, Blue, Claret Violet, Cream White, Curry, Gray, Heather Violet, Leaf Green, Light Green, Nut Brown, Pastel Orange, Water Blue, Yellow Green
Connector Type: Plug
Contact Material: Copper
Contact Type: Male Pin
Contacts: 4+2 Pin
Impedance: 100 ohm
Quick View

HSD Connector Short Right Angle Female HSD LVDS4+2p Automotive HD Signal Transmission Connector

Connector Type: Plug
Contact Type: Male Pin
Shield Termination: Solder
Quick View

HSD Connector Short Right Angle Female HSD LVDS4+2p Automotive HD Signal Transmission Connector

Connector Type: Plug
Contact Type: Male Pin
Shield Termination: Solder
Quick View

HSD Plug Connector Straight 4+4 Pin Cable Mount

Cable Color: Beige, Black, Blue, Claret Violet, Cream White, Curry, Gray, Heather Violet, Leaf Green, Light Green, Nut Brown, Pastel Orange, Water Blue, Yellow Green
Connector Type: Plug
Contact Material: Copper
Contact Type: Male Pin
Contacts: 4+4 Pin
Impedance: 100 ohm
